HPE ProLiant DL360 Gen10 Plus Server

Do you need to efficiently expand or refresh your IT infrastructure to propel the business?

HPE ProLiant DL360 Gen10 Plus server delivers enhanced performance with the right balance of expandability and density.




Adaptable for diverse workloads and environments, the compact 1U HPE ProLiant DL360 Gen10 Plus server delivers enhanced performance with the right balance of expandability and density. Designed for supreme versatility and resiliency while backed by a comprehensive warranty, the HPE ProLiant DL360 Gen10 Plus server is ideal for IT infrastructure, either physical, virtual, or containerized.

Powered by 3rd Generation Intel® Xeon® Scalable Processors, delivering up to 40 cores, 3200 MT/s memory, and introducing PCIe Gen4 and Intel Software Guard Extension (SGX) support to the dual-socket segment, the HPE ProLiant DL360 Gen10 Plus server delivers premium compute, memory, I/O, and security capabilities for customers focused on performance at any cost.

  • Supports 3rd Generation Intel® Xeon® Scalable Processors for enhanced compute performance.
  • 64 PCIe Gen4 lanes, resulting in more devices, improved bandwidth and augmented balanced I/O capabilities.
  • Support for industry-standard OCP 3.0 Network Adapters, enhancing customer choice.
  • Enhanced storage capabilities with Tri-mode controllers supporting NVMe/SAS/SATA drives, allowing customers to select the ideal media type and mix for their exact application.
  • Choice of storage backplanes and cages, offering diverse bay counts, protocols, and bandwidth that enable customers to design their server storage for their precise needs.
  • Slot-less HW RAID protected M.2 boot solution, providing peace-of-mind O/S deployment while saving invaluable slots and storage bays.

360-degree Holistic Security

The HPE ProLiant DL360 Gen10 Plus server provides an enhanced holistic, 360-degree view to security that begins in the manufacturing supply chain and concludes with a safeguarded, end-of-life decommissioning.

HPE ProLiant security begins with the corruption-free manufacture of the server and auditing the integrity of every component – hardware and firmware – to provide verification that the server begins its lifecycle uncompromised through the supply chain.

HPE ProLiant servers provide rapid detection of a security-compromised server, even to the point of not allowing it to boot, identify and contain malicious code, and protect healthy servers.

HPE ProLiant servers provide automated recovery from a security event, including restoration of validated firmware, and facilitating recovery of operating system, application, and data connections, providing a fast path to bring a server back online and into normal operations.

When it’s time to retire or repurpose an HPE ProLiant server, one button secure erase speeds and simplifies the complete removal of passwords, configuration settings, and data, preventing inadvertent access to previously secured information.

Intelligent Management Automation

The HPE ProLiant DL360 Gen10 Plus server simplifies and automates management tasks, establishing a solid foundation for a standards-based, hybrid cloud platform enabled by automation.

Embedded in Hewlett Packard Enterprise servers, HPE Integrated Lights-Out(iLO) is an exclusive core intelligence that monitors server status, providing the means for reporting, ongoing management, service alerting, and local or remote management to quickly identify and resolve issues.

Automation and software-defined control reduces time spent on provisioning and maintenance, and reduces deployment times.

HPE InfoSight for Servers continually analyzes server infrastructure and applies real-world examples of hundreds of thousands of servers to predict and prevent problems before they can adversely affect business operations.

Delivered As-a-Service

The HPE ProLiant DL360 Gen10 Plus server is supported by HPE GreenLake to simplify IT. With 24x7 monitoring and management, our experts do the heavy lifting to manage your environment with services built into consumption-based solutions.

Hewlett Packard Enterprise provides customers choice in how they acquire and consume IT. Beyond traditional financing and leasing, HPE offers options that free trapped capital, accelerate infrastructure updates and provide for on-premises pay-per-use consumption with HPE GreenLake.

Rapidly deploy a broad portfolio of cloud services such as, containers, compute, virtual machines (VMs), accelerated storage, data protection, and more. Workload-optimized, preconfigured solutions can be quickly on-boarded, accelerating your agility

Delivered as-a Service

The HPE ProLiant DL360 Gen10 Plus server is supported by HPE GreenLake to simplify IT infrastructure management across your entire hybrid estate. With 24x7 monitoring and management, our experts do the heavy lifting to manage your environment with services built into consumption-based solutions.

Rapidly deploy a broad portfolio of cloud services such as machine learning operations (ML Ops), containers, storage, compute, virtual machines (VMs), data protection, and more. Workload-optimized, preconfigured solutions can be delivered to your facility quickly, decreasing your downtime.

Hewlett Packard Enterprise provides customers choice in how they acquire and consume IT beyond traditional financing and leasing, offering options that free trapped capital, accelerate infrastructure updates, and provide for on-premises pay-per-use consumption with HPE GreenLake.

Technical Specifications:

Processor Type

  • Intel®

Processor Family

  • Intel® Xeon® Scalable 8300 series Intel® Xeon® Scalable 6300 series

Processor Core Available

  • 8 to 40 core, depending on processor

Processor Cache Installed

  • 12 - 60 MB L3, depending on processor

Maximum Memory

  • 6.0 TB per socket, when populated with 256 GB DDR4 and 512 GB Persistent Memory

Memory Slots

  • 16 DIMM slots per socket

Memory Type

  • HPE DDR4 SmartMemory

NVDIMM Type

  • Optional: Intel® Optane™ Persistent Memory for HPE

NVDIMM Capacity

  • Optional: 128 to 512 GB

Memory Protection Features

  • HPE Fast Fault Tolerant Memory Advanced ECC Memory Online Spare Memory Mirrored Memory

Drive Supported

  • Up to 4 LFF SAS/SATA HDDs or SSDs Up to 10 SFF SAS/SATA HDDs or SATA/SAS/NVMe U.2 or U.3 SDDs, depending on model

Network Controller

  • Wide range of speeds, cabling, chipsets and form factors. Please see QuickSpecs for network card choices

Remote Management Software

  • Included - HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) Optional - HPE iLO Advanced, and HPE OneView Advanced

Expansion Slots

  • Maximum 3 PCIe Gen4, for detail descriptions please see QuickSpecs

Storage Controller

  • Included - Embedded SATA controller (AHCI or SR100i modes) Optional - Variety of protocols -including NVMe-, port count, array utilities, and form factors. Please see QuickSpecs for storage controllers selection

Processor Name

  • 3rd Generation Intel® Xeon® Scalable Processor Family

Processor Number

  • 1 or 2

Processor Speed

  • 3.6 GHz, maximum depending on processor

Standard Memory

  • 4 TB (16x 256 GB) RDIMM per socket 6 TB (8x 256 GB RDIMM and 8x 512 GB Persistent Memory) per socket, depending on processor model

Security

  • UEFI Secure Boot and Secure Start support Intel® Software Guard Extensions (SGX) support Immutable Silicon Root of Trust Optional Trusted Supply Chain, iLO Security modes, TPM, Chassis Intrusion detection and Bezel Locking kits

Form Factor

  • 1U Rack

Weight (imperial)

  • SFF: 28.74 lb to 35.86 lb LFF: 30.36 lb to 37.00 lb

Weight (metric)

  • SFF: 13.04 kg to 16.27 kg LFF: 13.77 kg to 16.78 kg

Product Dimensions (imperial)

  • SFF: 1.69 x 17.11 x 30.30 in LFF: 1.69 x 17.11 x 31.50 in

Product Dimensions (metric)

  • SFF: 4.29 x 43.46 x 76.96 cm LFF: 4.29 x 43.46 x 80.01 cm

Persistent Memory Type

  • Optional: Intel® Optane™ Persistent Memory for HPE

Persistent Memory Media Capacity

  • Optional: 128 to 256 GB
